7 Albemarle Street - London W1S
A Grade II* listed terraced building built circa 1732 and listed 1958.
The works were undertaken with supervision from the Planning Authority.
Main Contractor - StructureTone Ltd
Architect - Farrells
Planners - Westminster
The problem - heritage window repairs needed
Rot and damage to all timber sash windows and frames.
The solution - heritage timber windows repaired
|
The works consisted of renovating all timber double hung sash windows, replacing sash cords, pulleys, brush pile and fasteners. Rotten/damaged frames and sashes were repaired with "Repair Care" resin.
Laminated annealed glass was installed into front elevation to improve acoustic properties.
|
Internal window shutters to ground and first floor were released and brought into servicable condition after being screwed shut and painted over for many decades.
|
|
Ashlyns School, Berkhampsted
Ashlyns School is a grade listed building constructed in the early 1930's. The windows are fabricated from mild steel with glazing formed by annealed 4 mm glass fixed with putty.
The works were undertaken with the supervision of the Planning Authority.
Main contractor: T & E Neville Ltd.
Planners: Bedfordshire Council.
The problem - heritage windows need repair
|
An existing wing unused for aconsiderable period is to be converted into a Music Room, the windows require upgrading to improve the overall operation of the windows and improve the glazing "u" value from 6W/m2K to 2.1W/m2K. |
|
The solution
- heritage window repairs
|
The windows were stripped back to bare metal and primed, all hinges/pivots/stays were eased to ensure a satisfactory operation.
The sashes were re glazed with a 4/6/4 sealed unit with Pilkington "K" coating applied to one surface, the glazing beads were formed from hardwood to reduce cold bridging to a minimum, resulting in a significant reduction in overall "U" value.
|
|
